Priority Research Paper Volume 4, Issue 4 pp 256—269

cep-1/p53-dependent dysplastic pathology of the aging C. elegans gonad

class="figure-viewer-img"

Figure 9. cep-1 worms have earlier uterine mass onset.

a, Partial maximum projection of mid-section of 6 individual whole wild-type worms stained with DAPI 12-days-old raised at 20 degrees. b, Partial maximum projection of mid-section of 6 individual whole cep-1 worms stained with DAPI 12-days-old raised at 20 degrees. Uterine masses are visibly larger in cep-1 (b) than wild-type (a). Scale bar represents 100 microns.
