Research Paper Volume 12, Issue 20 pp 20413—20431

Systemic analyses of expression patterns and clinical features for GIMAPs family members in lung adenocarcinoma

class="figure-viewer-img"

Figure 10. Association of protein expression of distinct GIMAPs with tumor grades of LUAD patients (UALCAN). protein expression of GIMAPs were significantly related to tumor grade, as tumor grade increased, the protein expression of GIMAPs tended to be higher (AH). **p<0.01, ***p<0.001.
